Gelei Cables is a professional company specializing in the production and manufacture of communication cables and power transmission conductor materials.
English
Application
1. THW cable
2. Extension cable
3. Rf cable
4. Building cable
5. Boost/battery cable
6. Welding cable
7. Speaker cable
Specification and Technology date | ||||
Section area (mm²) | Structure (number/mm) | Resistance (Ω/km)max | Tensile Strength (Mpa) | Elongation |
0.60/0.50 | 19/0.20 | 42.20 | 100-150 | 1-25 |
0.75 | 19/0.23 | 34.18 | ||
1.00 | 19/0.26 | 26.75 | ||
1.50 | 19/0.32 | 17.65 | ||
2.00 | 19/0.36 | 13.95 | ||
2.50 | 19/0.41 | 10.32 | ||
3.00 | 19/0.47 | 8.32 | ||
4.00 | 19/0.53 | 6.48 | ||
5.00 | 19/0.59 | 5.23 | ||
8.00 | 19/0.73 | 3.42 | ||
10.00 | 19/0.82 | 2.7 | ||
15.00 | 19/1.01 | 1.75 | ||
20-400 | All technology data and structure are complied customer's request | |||
