Application
General purpose wiring for lighting and power-residential, commercial, industrial buildings in accordance with the National Electrical Code, maximum conductor temperature of 75"C in wet or dry locations, for circuits not exceeding 600 volts.
Conductor sectional | Wire number | Wire dia | Conductor | Insulator thickness (mm) | Outer dia (mm) | Weight (mm) |
2.5 | 7 | 0.66 | 1.92 | 0.8 | 3.5 | 32 |
4 | 7 | 0.84 | 2.44 | 0.8 | 4.1 | 47 |
6 | 7 | 1.02 | 2.98 | 0.8 | 4.6 | 67 |
10 | 7 | 1.33 | 3.99 | 1.1 | 6.2 | 117 |
16 | 7 | 1.69 | 4.67 | 1.5 | 7.7 | 186 |
25 | 7 | 2.13 | 5.88 | 1.5 | 8.9 | 278 |
35 | 7 | 2.51 | 6.92 | 1.5 | 10 | 375 |
50 | 19 | 1.77 | 8.15 | 2 | 12.3 | 520 |
70 | 19 | 2.13 | 9.78 | 2 | 13.9 | 724 |
95 | 19 | 2.51 | 11.55 | 2 | 15.7 | 981 |
120 | 37 | 2.02 | 13 | 2.4 | 18 | 1245 |
150 | 37 | 2.24 | 14.41 | 2.4 | 19.4 | 1508 |
185 | 37 | 2.51 | 16.16 | 2.4 | 21.1 | 1866 |
240 | 37 | 2.87 | 18.51 | 2.4 | 23.5 | 2416 |
300 | 37 | 3.22 | 20.73 | 2.8 | 26.5 | 3041 |
400 | 61 | 2.84 | 23.51 | 2.8 | 29.3 | 3846 |
500 | 61 | 3.21 | 26.57 | 2.8 | 32.3 | 4862 |
