Application
1.The connection between solar cell modules
2.The connection between the battery and the inverter
3.The connection between the battery array and the controller or the DC junction box.
Section mm² | Insulation thickness (mm) | Approximate outside diameter (mm) | Reference weight (kg/km) | Maximum resistance at 20℃ (Ω/km) |
1.5 | 0.7 | 4.5 | 27 | 19.9 |
2.5 | 0.7 | 5.0 | 34 | 11.9 |
4 | 0.7 | 6.0 | 42 | 7.45 |
6 | 0.7 | 6.2 | 52 | 4.96 |
10 | 0.8 | 8.3 | 87 | 2.98 |
16 | 0.8 | 9.4 | 112 | 1.86 |
25 | 1.0 | 11.7 | 172 | 1.19 |
35 | 1.0 | 13.6 | 220 | 0.827 |
50 | 1.2 | 16.0 | 310 | 0.579 |
70 | 1.2 | 18.1 | 413 | 0.413 |
95 | 1.4 | 20.4 | 542 | 0.331 |
120 | 1.4 | 22.3 | 644 | 0.248 |
150 | 1.6 | 25.5 | 730 | 0.199 |
185 | 1.6 | 28.0 | 895 | 0.156 |
240 | 1.8 | 31.7 | 1015 | 0.124 |
